TDA3561A Elektronikai alkatrészek-IC

TDA3561A Elektronikai alkatrészek-IC

706

Decoder, Color Decoder 28 p.

1 db raktáron

2 890 Ft‎ (bruttó)

Pin-No.1 positive supply voltage (+12V)
Pin-No.2 control voltage for identification
Pin-No.3 chrominance input
Pin-No.4 reference voltage for A.C.C. detector
Pin-No.5 control voltage A.C.C.
Pin-No.6 saturation control
Pin-No.7 contrast control
Pin-No.8 sandcastle and field blanking input
Pin-No.9 video switch input
Pin-No.10 luminance input
Pin-No.11 brightness control
Pin-No.12 red signal output
Pin-No.13 red signal input
Pin-No.14 green signal output
Pin-No.15 green signal input
Pin-No.16 blue signal output
Pin-No.17 blue signal input
Pin-No.18 black level clamp capacitor
Pin-No.19 black level clamp capacitor
Pin-No.20 black level clamp capacitor
Pin-No.21 B-Y demodulator input
Pin-No.22 R-Y demodulator input
Pin-No.23 burst phase detector output
Pin-No.24 burst phase detector output
Pin-No.25 reference oscillator
Pin-No.26 reference oscillator
Pin-No.27 ground
Pin-No.28 chroma amplifier output
